RS-485 Communication Features
No.
Name
Description
BI12
P3 Input
1–True / 0–False
BI13
P4 Input
1–True / 0–False
BI14
P5 Input
1–True / 0–False
BI15
P6 Input
1–True / 0–False
BI16
P7 Input
1–True / 0–False
BI17
Relay1 State
1–On / 0 - Off
BI18
Relay2 State
1–On / 0 - Off
BI19
Relay3 State
1–On / 0 - Off
BI20
Relay4 State
1–On / 0 - Off
BI21
Relay5 State
1–On / 0 - Off
BI22
Q1 (OC1) State
1–On / 0 - Off
7.5.3.5 Error Code
Defined Codes
Description
00
The device has been reset. Currently waiting for the ‗Identity Yourself‘
command.
01
Undefined command
02
Checksum error has occurred.
03
Data size exceeded the input buffer (meaasage is bigger than the
device buffer size).
05
Data field error (input message size does not fit the command type)
10
Invalid data (message value is out of the range)
11
Invalid command for data type (command does not fit the message
frame)
12
Command is not accepted (device has ignored a command due to a
fault. The master device sends a ‗Status Update Request‘).
