z Function group 1
LED
display
Address
for
communi
cation
Paramet
er name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
Page
F 0 A200 [Jump
code]
0 ~ 71 Sets the parameter code number to jump. 1 O 4-5
F 1
A201
[Forwar
d/
Reverse
run
disable]
0 ~ 2
0
Fwd and rev run enable
0 X 7-10
1 Forward run disable
2
Reverse run disable
F 2 A202 [Accel
pattern]
0 ~ 1
0
Linear 0 X 7-15
F 3 A203 [Decel
pattern]
1
S-curve
F 4 A204 [Stop
mode
select]
0 ~ 3
0 Decelerate to stop
0 X 7-20
1 DC brake to stop
2 Free run to stop
3 Power Braking stop 8-26
F 8
1)
A208 [DC
Brake
start
frequen
cy]
0.1 ~ 60
[Hz]
This parameter sets DC brake start
frequency.
It cannot be set below F23 - [Start
frequency].
5.00 X 8-1
F 9
A209 [DC
Brake
wait
time]
0 ~ 60
[sec]
When DC brake frequency is reached,
the inverter holds the output for the
setting time before starting DC brake.
0.1 X
F10
A20A [DC
Brake
voltage]
0 ~ 200
[%]
This parameter sets the amount of DC
voltage applied to a motor.
It is set in percent of H33 – [Motor rated
current].
50 X
F11
A20B [DC
Brake
time]
0 ~ 60
[sec]
This parameter sets the time taken to
apply DC current to a motor while motor
is at a stop.
1.0 X
F12 A20C [DC
Brake
start
voltage]
0 ~ 200
[%]
This parameter sets the amount of DC
voltage before a motor starts to run.
It is set in percent of H33 – [Motor rated
current].
50 X 8-2
F13 A20D [DC
Brake
start
time]
0 ~ 60
[sec]
DC voltage is applied to the motor for DC
Brake start time before motor
accelerates.
0 X
F14 A20E [Time
for
magneti
zing a
motor]
0 ~ 60
[sec]
This parameter applies the current to a
motor for the set time before motor
accelerates during Sensorless vector
control.
0.1 X 8-15
F20 A214 [Jog
frequen
cy]
0 ~ 400
[Hz]
This parameter sets the frequency for
Jog operation.
It cannot be set above F21 – [Max
frequency].
10.00 O 8-3
1)
: Only displayed when F 4 is set to 1 (DC brake to stop).
