LSIS SV-iG5A Series User Manual

5-4
z Function group 1
LED
display
Address
for
communi
cation
Paramete
r name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
Page
F21
1)
A215 [Max
frequency
]
40 ~ 400
[Hz]
This parameter sets the highest frequency
the inverter can output.
It is frequency reference for Accel/Decel
(See H70)
60.00 X 7-21
Caution
Any frequency cannot be set above Max
frequency except Base frequency
F22 A216 [Base
frequency
]
30 ~ 400
[Hz]
The inverter outputs its rated voltage to the
motor at this frequency (see motor
nameplate).
60.00 X 7-17
F23 A217 [Start
frequency
]
0.1 ~ 10
[Hz]
The inverter starts to output its voltage at
this frequency.
It is the frequency low limit.
0.50 X 7-21
F24 A218 [Frequen
cy
high/low
limit
select]
0 ~ 1 This parameter sets high and low limit of
run frequency.
0 X 7-21
F25
2)
A219 [Frequen
cy high
limit]
0 ~ 400
[Hz]
This parameter sets high limit of the run
frequency.
It cannot be set above F21 – [Max
frequency].
60.00 X
F26
A21A [Frequen
cy low
limit]
0.1 ~ 400
[Hz]
This parameter sets low limit of the run
frequency.
It cannot be set above F25 - [Frequency
high limit] and below F23 – [Start
frequency].
0.50 X
F27 A21B [Torque
Boost
select]
0 ~ 1 0 Manual torque boost 0 X 7-19
1 Auto torque boost
F28 A21C [Torque
boost in
forward
direction]
0 ~ 15
[%]
This parameter sets the amount of torque
boost applied to a motor during forward
run.
It is set in percent of Max output voltage.
2 X 7-19
F29 A21D [Torque
boost in
reverse
direction]
This parameter sets the amount of torque
boost applied to a motor during reverse
run.
It is set as a percent of Max output voltage
2 X 7-19
1)
: If H40 is set to 3 (Sensorless vector), Max. frequency is settable up to 300Hz.
2)
: Only displayed when F24 (Frequency high/low limit select) is set to 1.
