LSIS SV-iG5A Series User Manual

5-19
Input/output group
LED
display
Address
for
communi
cation
Parameter
name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
Page
I 0
A400 [Jump code]
0 ~ 87 Sets the code number to jump. 1
O
4-5
I 2 A402 [NV input
Min voltage]
0 ~ -10
[V]
Sets the minimum voltage of the NV (-
10V~0V) input.
0.00 O 7-2
I 3 A403 [Frequency
correspondi
ng to I 2]
0 ~ 400
[Hz]
Sets the inverter output minimum
frequency at minimum voltage of the NV
input.
0.00 O
I 4 A404 [NV input
Max
voltage]
0 ~ -10
[V]
Sets the maximum voltage of the NV
input.
10.0 O
I 5 A405 [Frequency
correspondi
ng to I 4]
0 ~ 400
[Hz]
Sets the inverter output maximum
frequency at maximum voltage of the
NV input.
60.00 O
I 6 A406 [Filter time
constant for
V1 input]
0 ~ 9999 Adjusts the responsiveness of V1 input
(0 ~ +10V).
10 O 7-2
I 7 A407 [V1 input
Min voltage]
0 ~ 10
[V]
Sets the minimum voltage of the V1
input.
0 O
I 8 A408 [Frequency
correspondi
ng to I 7]
0 ~ 400
[Hz]
Sets the inverter output minimum
frequency at minimum voltage of the V1
input.
0.00 O
I 9 A409 [V1 input
Max
voltage]
0 ~ 10
[V]
Sets the maximum voltage of the V1
input.
10 O
I10 A40A [Frequency
correspondi
ng to I 9]
0 ~ 400
[Hz]
Sets the inverter output maximum
frequency at maximum voltage of the
V1 input.
60.00 O
I11 A40B [Filter time
constant for
I input]
0 ~ 9999 Sets the input section’s internal filter
constant for I input.
10 O 7-4
I12 A40C [I input Min
current]
0 ~ 20
[mA]
Sets the minimum current of I input. 4.00 O
I13 A40D [Frequency
correspondi
ng to I 12]
0 ~ 400
[Hz]
Sets the inverter output minimum
frequency at minimum current of I input.
0.00 O
I14 A40E [I input Max
current]
0 ~ 20
[mA]
Sets the Maximum current of I input. 20.00 O
I15 A40F [Frequency
correspondi
ng to I 14]
0 ~ 400
[Hz]
Sets the inverter output maximum
frequency at maximum current of I
input.
60.00 O 7-4
I16 A410 [Criteria for
Analog Input
Signal loss]
0 ~ 2 0: Disabled
1: activated below half of set value.
2: activated below set value.
0 O 10-7
I17 A411 [Multi-
function
input
terminal P1
define]
0 ~ 27 0 Forward run command 0 O 7-8
1 Reverse run command
I18 A412 [Multi-
function
input
terminal P2
define]
2 Emergency Stop Trip 1 O -
3 Reset when a fault occurs {RST} -
