7-10
z Rotating direction select via –10 ~ +10[V] input of V1 terminal
Group Code Parameter Name Setting Range Initial Unit
Drive group
frq [Frequency setting] 2
0 ~ 8 0
drv [Drive mode] - 0 ~ 3 1
Set frq to 2.
Inverter is operating as the table below regardless of Drive mode setting.
FWD RUN Command REV RUN Command
0 ~ +10 [V] FWD RUN REV RUN
-10 ~ 0 [V] REV RUN FWD RUN
Motor runs in Forward direction when input voltage to V1-CM is 0~10[V] and FWD RUN
command is active. When input voltage polarity is reversed to –10~0[V] during FWD RUN, motor
decelerates to stop and runs in reverse direction.
When input voltage to V1-CM is 0~10[V] and REV RUN command is active, motor runs in
Reverse direction and if -10~0[V] is input, motor rotating direction is reverse.
z FX/RX Run Disable
Group Code Parameter Name Setting Range Initial Unit
Drive group drC
[Direction of motor
rotation select]
- F, r F
Function group 1
F 1
[Forward/Reverse run
disable]
-
0 ~ 2 0
Select the direction of motor rotation.
0: Forward and Reverse run enable
1: Forward run disable
2: Reverse run disable
