(1) Operating Channel Setting
The default setting for operating channel is ‘Stop.’
Bit15 Bit14 Bit13 Bit12 Bit11 Bit10 Bit9 Bit8 Bit7 Bit6 Bit5
Bit4 Bit3 Bit2 Bit1 Bit0
C
H
.
3
C
H
.
2
C
H
.
1
C
H
.
0
C
H
.
6
C
H
.
7
----
Address0
Appoint Using CH
Bit On (1): Operate
Bit Off (0): Stop
----
C
H
.
4
C
H
.
5
(2) Input Range Setting
(a) The analog input voltage range is DC 1~5V, DC 0~5V, DC 0~10V, and analog current input
range is DC 4~20mA, DC 0~20mA.
(b) Default range is DC 4~20mA.
BIT 15 BIT14 BIT 13 BIT12 BIT 11 BIT10 BIT9 BIT 8
BIT7
BIT6
BIT5
BIT4 BIT3 BIT 2 BIT1 BIT 0
CH
0
Address1
Input range setting (4 bit per channel)
0 : 4 ~ 20
㎃
1 : 0 ~ 20
㎃
2 : 1 ~ 5 V
3 : 0 ~ 5 V
4 : 0 ~ 10 V
CH
1
CH
2
CH
3
BIT 15
BIT 14 BIT13 BIT 12 BIT11
BIT 10 BIT 9
BIT8 BIT7 BIT 6 BIT5 BIT 4
BIT3
BIT2 BIT1
BIT0
CH
4
Address2
CH
5
CH
6
CH
7
(3) I/O Data Type Setting
(a) I/O data type can be set up for each channel.
(b) If the I/O data type is not set up, all the channels are processed in 0~4000 range.
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Address3
Input data type setting (2bit per channel))
0 : 0 ~ 4000
1 : -2000 ~ 2000
2 : Precise value
3 : 0 ~ 1000
CH 7
- For precise value
4 ~ 20 ㎃: 400 ~ 2000
0 ~ 20 ㎃: 0 ~ 2000
1 ~ 5 V: 100 ~ 500
0 ~ 5 V: 0 ~ 500
0 ~ 10 V: 0 ~ 1000
CH 6 CH 5 CH 4 CH 3 CH 2 CH 1 CH 0
