Chapter 7 Analog Input Module (XBF-AD08A)
(4) Filter Constant Setting
(a) If set to 0, no filtration is processed.
(b) Default setting is 0 – no filtration process.
Bit 15 Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
CH 0 filter constant (0 or 4~64000ms)
Address4
Address5
Address6
Address7
Address8
Address9
Address10
Address11
CH 1 filter constant (0 or 4~64000ms)
CH 2 filter constant (0 or 4~64000ms)
CH 3 filter constant (0 or 4~64000ms)
CH 4 filter constant (0 or 4~64000ms)
CH 5 filter constant (0 or 4~64000ms)
CH 6 filter constant (0 or 4~64000ms)
CH 7 filter constant (0 or 4~64000ms)
(5) Averaging Method Setting
(a) Averaging method can be one of; time average, count average, moving average.
(b) Default setting is no averaging throughout the channels.
Bit 15 Bit 14 Bit 13 Bit 12
Bit 11 Bit 10 Bit 9 Bit 8 Bit 7
Bit 6
Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
CH
0
Address12
Average processing (4 bit per channel)
0 :
Sampling Processing
1 :
Time average processing
2 :
Count average processing
3 :
Moving average processing
CH
1
CH
2
CH
3
CH
4
CH
5
CH
6
CH
7
7 - 33
