(6) Average Value Setting
(a) Set up average values in accordance with the setting area of the averaging method.
(b) If the average value is out of setting range, averaging is not applied.
Bit 15 Bit 14
Bit 13 Bit 12
Bit 11
Bit 10 Bit 9
Bit 8 Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2 Bit 1
Bit 0
CH 0 average value
Address13
Address14
Input channel # average value setting
Time average
: 4 ~ 16000 [ms]
Count average
: 2 ~ 64000 [times]
Moving average
: 2 ~ 100
Address15
Address16
Address17
Address18
Address19
Address20
CH 1 average value
CH 2 average value
CH 3 average value
CH 4 average value
CH 5 average value
CH 6 average value
CH 7 average value
(7) Error Code (Address 21)
(a) Saves the error code detected by the analog mix module.
(b) The types and descriptions of the error are as follows.
Bit15 Bit14
Bit13
Bit12 Bit11
Bit10 Bit9
Bit8 Bit7
Bit6 Bit5
Bit4 Bit3
Bit2
Bit1 Bit0
Set-up error information
Address21
Type
Error
code
LED Description
Error code
Priority
Remark
Error
10#
LED
flickering
1s intervals
Channel range set-up error 1
# channel no.
CH 0~7
20# Channel filter constant set-up error 2
30# Channel average value set-up error 3
(c) In case of plural errors, the code with higher priority order will be saved.
(9) System Area (after Address 22)
(a) System area (after address 22) is read/write protected.
Caution
Modifying this area can cause malfunction of failure of product.
7 - 34
