Chapter 6. Panel Editor
6-67
1) X-axis/Y-axis
(1) Enables or disables X-axis and Y-axis.
(2) If just one is selected between X and Y, linear movement will be allowed to the selected direction. And if all of the two
axes selected, plane movement will be allowed. At least one of them has to be enabled.
2) Select Image
(1) Allows the image used in Move Tag to be edited and added as requested by the user.
(2) See 6.3 for details on Edit Image and Add Image.
2) Application Example of Move Tag
For an application example, the property of the Move Tag is specified as shown below.
To Next Page
