8.3 LS MASTER-K Series (80S/120S/200S/300S/1000S) : Dedicated
Protocol
8.3.1 Communication Mode
Connection is available through LS MASTER-K series of PLC and the Dedicated Protocol.
If connected with LS MASTER-K series and the Dedicated Protocol, its applicable communication setting is as follows.
At this moment, the applicable communication setting of PLC and the XGT Panel to be connected between should be set
identical to each other.
Setting Contents
Setting Item
CH 1 CH 2
Remarks
Communication
Mode
RS-232C RS-422, RS-485 -
Instrument Sided
Connector
9-Pin Male connector Terminal plate or connector -
Connection
Protocol
MASTER-K Dedicated Protocol -
Communication
Speed
1,200/2,400/4,800/9,600/19,200/38,400/57,600bps -
Data Bit 7Bits, 8Bits -
Parity Bit None, Even Bits, Odd Bits -
Stop Bits 1 Bit, 2 Bits -
Station No. 0 ~ 31
Station No. unavailable if
identical to XGT Panel
- Connectable PLC module list
CPU module
Communication
method
Connection module Reference
RS-232C G3L-CUEA Cnet module
1000S
RS-422/485 G3L-CUEA Cnet module
RS-232C G4L-CUEA Cnet module
300S
RS-422/485 G4L-CUEA Cnet module
RS-232C CPU module Built-in Cnet
RS-232C G6L-CUEB Cnet module
200S
RS-422/485 G6L-CUEC Cnet module
RS-232C CPU module Built-in Cnet
RS-485 CPU module Built-in Cnet
RS-232C G7L-CUEB Cnet module
120S
RS-422/485 G7L-CUEC Cnet module
RS-232C CPU module Built-in Cnet
RS-485 CPU module Built-in Cnet
RS-232C G7L-CUEB Cnet module
80S
RS-422/485 G7L-CUEC Cnet module
