Chapter 3. General Specifications
3-1
Chapter 3. General Specifications
3.1 General Specifications
The following table shows the general specifications of the XGT Panel.
No. Item Specifications References
1
Operating ambient
temperature
0 ~ 50 °C
2
Storage ambient
temperature
−20 ~ +60 °C
3
Operating ambient
humidity
5 ~ 85%RH, non-condensing
4
Storage ambient
humidity
5 ~ 85%RH, non-condensing
Occasional vibration -
Frequency Acceleration Amplitude Sweep count
10 ≤ f < 57Hz −
0.075mm
57 ≤ f ≤ 150Hz
9.8m/s
2
{1G}
−
Continuous vibration
Frequency Acceleration Amplitude
10 ≤ f < 57Hz −
0.0375mm
5 Vibrations
57 ≤ f ≤ 150Hz
4.9m/s
2
{0.5G}
−
10 times for each
X, Y, Z axis
IEC 61131-2
6 Shocks
• Maximum shock acceleration: 147 m/s
2
{15G}
• Duration time: 11ms
• Pulse wave: half sine pulse (3 shocks per axis, on X, Y, Z axis)
IEC 61131-2
Square wave
Impulse noise
± 500 V
LSIS’ Standard
Electronic
discharge
Voltage: 4 kV (Discharge by contact)
IEC 61131-2,
IEC 61000-4-2
Radiated
electromagnetic
field noise
27 ~ 500 MHz, 10 V/m
IEC 61131-2,
IEC 61000-4-3
7 Noise immunity
Fast transient &
Burst noise
Voltage
1kV
/ 0.25kV
IEC 61131-2
IEC 61000-4-4
8
Atmosphere Free of corrosive gases and excessive dust
9
Altitude
Up to 2,000m
10
Pollution degree
Less than 2
11
Cooling method
Air-cooling
REMARK
1) IEC (International Electro-technical Commission): An international civilian institute who establishes international standards in electronics.
2) Pollution degree: An indicator which determines the insulation performance of the equipment.
* Pollution degree 2: Normally, only non-conductive pollution occurs. Occasionally however, a temporary conductivity caused by condensation mat be
expected
