363-208-011
Cabling, Wiring, and Assembly
Issue 4 February 1997 3-45
Figure 3-28. DS1 OUT (17 - 28) Connections
Wiring Side
P163
P165
BL/W
O/W
GR/W
BR/W
S/W
BL/R
O/R
GR/R
BR/R
S/R
BL/BK
O/BK
RING
W/BL
W/GR
W/BR
W/S
R/BL
R/0
R/GR
R/BR
R/S
W/O
BK/BL
BK/O
TIP
DSX0 17
DSX0 18
DSX0 19
DSX0 20
DSX0 21
DSX0 22
DSX0 23
DSX0 24
DSX0 25
DSX0 26
DSX0 27
DSX0 28
1
20
12
31
