4-4 Issue 4 February 1997

363-208-011

Parts Lists and Kits

Peripheral Cables (as required)

Table 4-1A. Peripheral Cable Assemblies

* L is lower half of MDS Assembly; U is upper half.

NOTE:

Quantity Cable Assembly Function Channels/Shelf*

1 per COT ED7C723-37, G1(), 2(), or 3() DS1 IN 1 - 16 ARM

1 per COT ED7C723-37, G1(), 2(), or 3() DS1 IN 17 - 28 ARM

1 per COT ED7C723-37, G1(), 2(), or 3() DS1 OUT 1 - 16 ARM

1 per COT ED7C723-37, G1(), 2(), or 3() DS1 OUT 17 - 28 ARM

1 per MDS ED7C723-37, G4, 5, or 6 VF 1 - 96 MDS/L

1 per MDS ED7C723-37, G7, 8, or 9 VF 1 - 96 MDS/U

1 per MDS ED7C723-37, G10, 11, or 12 E&M 1 - 93 MDS/L

1 per MDS ED7C723-37, G13, 14, or 15 E&M 1 - 93 MDS/U

1 per COT ED7C723-37, G16, 17, or 18 Misc. Disc. Alms ARM

1 per COT ED7C723-37, G16, 17, or 18 Bypass Test ATU

1 per COT ED7C723-37, G19, 20, or 21 Telemetry ATU

1 per COT ED7C723-37, G27, 28, or 29 DS1 Timing ARM

ED7C723-37

Groups 1(), 4, 7, 10, 13, 16, 19, 27 75-foot cable assemblies

Groups 2(), 5, 8, 11, 14, 17, 20, 28 150-foot cable assemblies

Groups 3(), 6, 9, 12, 15, 18, 21, 29 speciﬁed lengths

Groups 1(), 2(), or 3() are used for DS1 Feeder or DS1 Distribution applica-

tions.
