Lucent Technologies SLC-2000 Access System Central Office Terminal User Manual

3-70 Issue 4 February 1997
363-208-011
Cabling, Wiring, and Assembly
Table 3-6. COT Parallel Telemetry Alarm and Status Points
Pin # Wire ID Type Description
1 TELR - Telemetry Return (Common)
2 CRT SA Critical Alarm
3 MNT NSA Minor Alarm
4 NE Status Near End (Site of COT)
5 SID Status System ID
6 CL4 SA Major Alarm
7 CL5 NSA Power Minor Alarm
8 CL6 Status Incoming LS Signal Failure
9 CL7 Status Incoming SONET Failure
10 CL8 Status Far End ID #1 (RT Failure Site)
11 CL9 Status Far End ID #2 (RT Failure Site)
12 CL10 Status Far End ID #3 (RT Failure Site)
13 CL11 Status Far End ID #4 (RT Failure Site)
14 CL12 Status Far End ID #5 (RT Failure Site)
15 CL13 Status Far End ID #6 (RT Failure Site)
NC CL14-CL19 NC No Connections
16 CL20 Status RACO verification
NC CL21-CL26 NC No Connections
17 CL27 Status Far End DLC Alarm
18 CL28 Status Far End ID #7 (RT Failure Site)
19 CL29 Status Far End ID #8 (RT Failure Site)
20 CL30 Status VRT ID #1 (VTU Alarm)
21 CL31 Status VRT ID #2 (VTU Alarm)
22 CL32 Status VRT ID #3 (VTU Alarm)
23 CL33 Status VRT ID #4 (VTU Alarm)
24 CL34 Status VRT ID #5 (VTU Alarm)
25 CL35 Status VRT ID #6 (VTU Alarm)
