363-208-011
Cabling, Wiring, and Assembly
Issue 4 February 1997 3-71
26 CL36 Status VRT ID #7 (VTU Alarm)
27 CL37 Status VRT ID #8 (VTU Alarm)
28 CL38 Status Digroup A
29 CL39 Status Digroup B
30 CL40 Status Digroup C
31 CL41 Status Digroup D
32 CL42 Status DLC CLF (DS1 Feeder or DT)
33 CL43 Status Abnormal Condition
34 CL44 Status Misc 1
35 CL45 Status Misc 2
36 CL46 Status Misc 3
37 CL47 Status Misc 4
38 CL48 Status Misc 5
39 CL49 Status Misc 6
40 CL50 Status Misc 7
41 CL51 NA Future Assignment
42 CL52 NA Future Assignment
43 CL53 NA Future Assignment
44 CL54 NA Future Assignment
45 CL55 NA Future Assignment
46 CL56 NA Future Assignment
47 CL57 NA Future Assignment
48 CL58 NA Future Assignment
49 CL59 NA Future Assignment
50 RACO Control Remote ACO
Pin # Wire ID Type Description
To Next Page
