4-6 Issue 4 February 1997
363-208-011
Parts Lists and Kits
Ancillary Equipment
Ringing Supplies
Ringing Supply shelf equipped with two +20 Hz/-20 Hz, 100 Vac Ringing Supplies
(Lucent Technologies J1C182BC or equivalent)
DC Power Supply
Two sources of -48 Vdc each protected by 30 amp circuit breaker
Cross-connect Blocks
Miscellaneous Cables
VF 100 pair blocks (2 required per MDS Assembly)
DS1 Optional blocks to terminate 28 shielded pairs each, transmit and receive
Fiber Optic Block to terminate up to 8 single-mode fibers
Power <30 feet: two 10-gauge pairs
>30 feet: two pairs gauged to limit dc drop to 1.5v maximum at 25
amps spliced down to 10 gauge before connecting to
ARM shelf Power Interface Unit
Ground No. 2 AWG ground wire or equivalent to meet local building standards
Fiber Optic one pair, single-mode fiber cables per
SLC
-2000 OLIU circuit pack
Ringing two 22-gauge twisted triples
Composite Clock 22 gauge shielded pair (primary) Comcode 106977572
22 gauge shielded pair (secondary) Comcode 106977606
To Next Page
