3-60 Issue 4 February 1997
363-208-011
Cabling, Wiring, and Assembly
E&M Connections
Installation Procedure for Cable
Assemblies ED7C723-37 Groups 10 to 15
NOTE:
This procedure consists of installing the E&M Customer Interface Cable
Assemblies (ED7C723-37 Groups 10 to 15) and mating their connectors to
the MDS Shelf backplane connectors.
NOTE:
Some pins on this 50 pin connector are not assigned. The rest are brought
out to the MDF for cross connections.
NOTE:
These cable are available in varying lengths, however any excess may be
cut off to relieve cable rack congestion.
NOTE:
VF channel numbering is from 1 to 96 for each MDS shelf. There are two
shelves per MDS Assembly (J1C265AE-1) with a total of eight shelves (4
assemblies) per 7 foot RT Bay (maximum of 768 quad channels). Each
shelf supports 96 channels.
NOTE:
System ID labels (furnished with the MDS Assembly) shall be filled out by
the customer in accordance with the route/system numbering scheme. The
MDF circuit labeling should follow this numbering pattern. Refer to the
APPLICATIONS chapter for typical cross-connect block numbering.
To Next Page
