Lucent Technologies SLC-2000 Access System Central Office Terminal - Section 2

xii Issue 4 February 1997
Tables
2 Installation Procedures
2-1. Dimensions for Figure 2-2 2-7
3 Cabling, Wiring, and Assembly
3-1. Cable Verification for ARM and MDS Shelves 3-11
3-2. VF Connections 3-47
3-3. VF Channel Number Identification 3-47
3-4. E&M Connections 3-61
3-5. E&M Channel Number Identification 3-61
3-6. COT Parallel Telemetry Alarm and Status Points 3-70
4 Parts Lists and Kits
4-1A. Peripheral Cable Assemblies 4-4
4-1B. Peripheral Cable Assemblies 4-5
A Applications
A-1. OSP Cable Pair/MDS Channel Numbering A-4
A-2. OSP Cable Pair/MDS E&M Channel Numbering A-6
