Lucent Technologies SLC-2000 Access System Central Office Terminal - Installer Cabling Operations; Power and Ringing Local Interfaces; PCM Connections; Test Access Path (TAP) Interface

Issue 4 February 1997 3-i
3
Cabling, Wiring, and Assembly
Contents
Cable Assembly Descriptions 3-1
■ Cable Description 3-1
Factory Assemblies 3-1
Customer Interface Cable Assemblies 3-1
Factory Cable Assembly Wire Color Coding Sequence 3-2
Connector Description 3-4
Cinch Connectors 3-4
D Type Connectors 3-5
AMP Mate-N-Lok II Connectors 3-6
Installer Cabling Operations 3-8
■ General 3-8
■ Shelf Cables Verification 3-11
■ Bay Local Cable Connections 3-14
Power and Ringing Local Interfaces 3-16
■ Power Interface Unit/Standard Bay Cable Connections 3-16
■ Power and Ringing Bay Cable Assembly ED7C723-34 Group 2 3-17
PCM Connections 3-22
■ Connecting Procedure for Cable Assemblies ED7C723-30
Groups 9A to 12A 3-22
Connections 3-22
Test Access Path (TAP) Interface 3-25
■ TAP Bay Cable Assembly ED7C723-34 Group 1 3-25
