363-208-011
Cabling, Wiring, and Assembly
Issue 4 February 1997 3-17
Power and Ringing Bay Cable Assembly
ED7C723-34 Group 2()
*
Step 1:
Refer to the Figure 3-10 and connect the Power Interface dangler cable
assembly as follows in the rear left side cable duct:
* The parenthesis after the group number of the cable assembly means that there may be an
alpha character after the numeric character, e.g., Group 2 or Group 2A or Group 2B.
Dangler Connector Mating Connector Comment
P304 ------- to be connected later
J114 P114 ATU to be connected later
P303 J303 ARM consult Figures 3-10 and 3-12
P302-4 J302 MDS 4 consult Figures 3-10 and 3-12
P302-3 J302 MDS 3 consult Figures 3-10 and 3-12
P302-2 J302 MDS 2 consult Figures 3-10 and 3-12
P302-1 J302 MDS 1 consult Figures 3-10 to 3-12
