Lucent Technologies SLC-2000 Access System Central Office Terminal User Manual

363-208-011
Cabling, Wiring, and Assembly
Issue 4 February 1997 3-25
Test Access Path (TAP) Interface
TAP Bay Cable Assembly ED7C723-34
Group 1
Step 1: Refer to Figures 3-17and 3-18 and connect the TAP Interface cable
assembly as follows in the right side cable duct:
Step 2: Position the unused/unassigned connectors so that future access for
additional growth shelves is possible. After the connections have been
made tie the cable assembly down towards the rear of the right duct.
TAP Connector Mating Connector
P301 to be connected later
J275 P275 ARM Shelf
J301-4 P301 MDS 4
J301-3 P301 MDS 3
J301-2 P301 MDS 2
J301-1 P301 MDS 1
