3-48 Issue 4 February 1997
363-208-011
Cabling, Wiring, and Assembly
Figure 3-29. MDS VF Cable Routing J101 - J104
MDS #4
P206 P106
P205 P105
P201
P202P203
P204
J101J102
J103J104
Cable
Tie
Points
Cable
Tie
Points
