363-208-011
Parts Description
Issue 4 February 1997 5-3
MDS Assembly Parts
The MDS assembly is provided by the manufacturer with the following individual
cable assemblies and hardware. The following listing can be used as an ordering
guide or as an installation checklist for material previously ordered. The material
that is indicated as optional is required for specific purposes. All pieces are
shipped with the shelf, but some parts (*) may be loosely attached or shipped in
separate containers.
J1C265AE-1 List 1 or 2 MDS Assembly
equipped with
ED7C723-32 Group 1 Cable Assembly
ED7C723-32 Group 10 Cable Assembly
ED7C723-32 Group 11() Cable Assembly
6 801486341* screws, special round head
2 402444491* studs, slotted
2 846944411* labels, system identification
2 406203182* fuses, 0.5 amp
4 406203976* fuses, 5.0 amp
