363-208-011
Parts Description
Issue 4 February 1997 5-11
Figure 5-6. Cable Assembly ED7C723-36, Group 4
50
45
40
35
30
26 1
5
10
15
20
25
BR/R
R/BR
BL/W
W/BL
O/W
W/O
G/W
W/G
BR/W
W/BR
S/W
W/S
BL/R
R/BL
O/R
R/O
G/R
R/G
WIRING SIDE
J173
1
13
14
25
WIRING SIDE
P1B
BL/W
W/BL
O/W
W/O
G/W
W/G
BR/W
W/BR
S/W
W/S
BL/R
R/BL
O/R
R/O
G/R
R/G
BR/R
R/BR
