1-14 Issue 1 November 1998
363-208-011, Appendix 1
NJ00675A-2 Dual Power Feed Unit Installation Procedure
Figure 2. COT Mounting and Cable Paths
Out
In
NE00675-31, G3 Cable Assembly (green/yellow)
NE00675-31, G1 Cable Assembly
NE00675-31, G2 Cable Assembly
TB4 -48R
TB3 -48B
TB2 -48R
TB1 -48A
PIU(opened)
J117
P117A
P117B
BAY FRAME GROUND
