Lumel ND30 User Manual

ND30-09D 54 User's manual
4054 RW
-1440..
0..1440
[
o
/
oo
]
Alarm output 1 - lower value of the condition 3
switch of the rated input range
900
4055 RW
-1440..
0..1440
[
o
/
oo
]
Alarm output 1 - upper value of the condition 3
switch of the rated input range
1100
4056 RW 0..3600 s Alarm output 1 - condition 3 activation delay 0
4057 RW 0..3600 s Alarm output 1 - condition 3 deactivation delay 0
4058 RW 0..3600 s Alarm output 1 - condition 2 re-activation lock 0
4059 RW
0,1
Alarm output 1– condition 2 signalization 0
4060 RW reserved
4061 RW
0…4
Alarm output 2 - Logic tasks of the conditions 1,
2, 3
0 – C1
1 – C1 v C2 v C3
2 – C1  C2  C3
3 – (C1  C2) v C3
4 – (C1 v C2  C3
0
4062 RW
0,1
Alarm output 2 - State of the relay at the alarm
switched on: 0 - relay disabled
1 - relay enabled
1
4063 RW
0,1
Alarm output 2 - alarm deactivation lock 0
4064 RW
0,1
Alarm output 2 - alarm signalization 0
4065 RW 0.1..54
Alarm output 2 - value for the condition 1 (c1)
(code as in Table 8)
38
4066 RW 0..9
Alarm output 2 - type for the condition 1: 0 –
n_on, 1 – noFF, 2 – on, 3 – oFF, 4 – H_on, 5 –
HoFF,
6 – 3non, 7 – 3noF, 8 – 3_on, 9 – 3_oF
0
4067 RW
-1440..
0..1440
[
o
/
oo
]
Alarm output 2 - lower value of the condition 1
switch of the rated input range
900
4068 RW
-1440..
0..1440
[
o
/
oo
]
Alarm output 2 - upper value of the condition 1
switch of the rated input range
1100
4069 RW 0..3600 s Alarm output 2 - condition 1 activation delay 0
4070 RW 0..3600 s Alarm output 2 - condition 1 deactivation delay 0
4071 RW 0..3600 s Alarm output 2 - condition 1 re-activation lock 0
4072 RW
0,1
Alarm output 2– condition 1 signalization 0
4073 RW reserved
4074 RW 0.1..54
Alarm output 2 - value for the condition 2 (c2)
(code as in Table 8) 38
4075 RW 0..9
Alarm output 2 - type for the condition 2:
0 – n_on, 1 – noFF, 2 – on, 3 – oFF, 4 – H_on,
5 – HoFF, 6 – 3non, 7 – 3noF, 8 – 3_on, 9 – 3_oF
0
