User Guide
28
© Copyright 2011 Luxul. All rights reserved. Trademarks & Registered Trademarks are property of respective holders.
5.10.2 802.1X Port Confi guration
Admin State: There are 3 options: Force Authorized, Force Unauthorized and
Auto. In “Forced Authorized” state, the port allows transmission of any message.
In “Forced Unauthorized” state, the port only allows transmission of authenti-
cated messages. In “Auto” state the port allows transmission of certain messages
according to the authentication result
NOTE: If using a RADIUS server, it is recommended to use the “Auto”
state setting.
Port State: Displays the 802.1X status of each port. Options include: 802.1X
disabled, Link Interrupted, Authorized or Unauthorized
Force Re-authenticate: Clicking the link forces the corresponding port to
perform reauthentication
5.11 RSTP
Rapid Spanning Tree Protocol (RSTP) can be used to create connection links for
redundancy and failover. To avoid loops, RSTP automatically assigns a root bridge
or root port and parameters are changed at the bridge level
5.11.1 RSTP Confi guration
5.11.2 RSTP Port
Confi guration
5.11.3 RSTP Status
NOTE: Because the RSTP algorithm is complex, it is recommended
to use default values. If modifi cation to RSTP parameters is
necessary, consult a networking expert and/or carefully read and
understand RSTP defi nitions and procedures.
