The following entries are displayed on this screen:
Protocol Group Table
Select:
Select the desired entry or entries.
Protocol:
Displays the Protocol of the Protocol Group.
VLAN ID:
Displays the corresponding VLAN ID of the Protocol Group.
Member:
Displays the member(s) of the Protocol Group.
Confi guration:
Click the Edit button to modify the settings of the entry, then click
the Modify button to apply your changes.
CAUTION: Protocol VLAN settings will be restored to defaults if the
Switch is restarted and you have not selected Save Confi g
from the main menu and saved your running confi guration to
non-volatile memory.
6.3.2 Protocol Group
On this page, you can create a Protocol Group.
Choose the menu VLAN>>Protocol VLAN>>Protocol Group to load the following page.
Figure 6-13 Create Protocol VLAN
