Magnamed Fleximag - Page 22

21
MAGNAMED TECNOLOGIA MÉDICA S/A
OK
Item
Assembly Sequence
3
Adequately connect the flow sensor and follow the
instructions on the right.
• All connections must be mounted
securely to prevent leakages.
4
Prepare the patient’s respiratory circuit, firmly
connection the inspiratory limb to the gas mix flow
source.
• Use the respiratory circuit that is
adequate to the patient.
