Item
Assembly Sequence
5
The expiratory circuit’s limb must be firmly
connected to the exhalation valve.
6
In the event the respiratory circuit is used for NON
INVASIVE VENTILATION (NIV) without filter.
7
In the event the respiratory circuit is used for NON
INVASIVE VENTILATION (NIV) with mask and
HME filter, follow the assembly to the right.
