95
MAGNAMED TECNOLOGIA MÉDICA S/A
High Priority Alarm
Delay time
Description
HIGH TIDAL VOLUME
< 3 cycles
The tidal volume delivered to the
patient exceeded the value of the
adjusted alarm as total volume of upper
limit.
LOW TIDAL VOLUME
< 3 cycles
The tidal volume delivered to the
patient is below the set alarm value and
total volume of lower limit.
Table 24 - Medium priority alarms
Medium Priority Alarm
Delay time
Description
NO AC POWER
< 1 s
It means that there is no power from the
power supply.
CHECK LEAKLAGE
< 2 cycles
The measured flow leak exceeded the
maximum compensation limit.
CHECK FLOW SENSOR
< 3 cycles
It indicates that there are problems with
the external flow sensor or is
disconnected. Under these conditions
all the monitoring that depends on this
sensor (VT, MV, Frequency, Vins, Tinsp,
I: E, T exp, Cst, DynC, Res, , iT, Volume
Leak, VxTime Chart) will NOT be
displayed. In controlled ventilation
modes the volume, the delivered
equipment volumes will have a range of
up to ± 10%.
HIGH MINUTE VOLUME
< 3 cycles
The minute volume delivered to the
patient exceeded the value of the alarm
set as its upper limit.
LOW MINUTE VOLUME
< 3 cycles
The minute volume delivered to the
patient is below the set alarm value to
its lower limit.
HIGH RATE
< 3 cycles
The respiratory rate of the patient
exceeded the alarm value set to its
upper limit.
LOW RATE
< 3 cycles
The respiratory rate of the patient
exceeded the alarm value set to its
lower limit.
HIGH PEEP
< 3 cycles
Positive pressure end-expiratory
pressure (PEEP) exceeded the alarm
value set to its upper limit.
