LT10A / LT11A Series
Initial setting :
For an overflow alarm
1st byte : Channel name (A or B)
2nd byte : Current mode
( N : Current value,
P : Peak-to-peak value,
I : Minimum value,
A : Maximum value)
3rd byte : Unit (M: mm, I: inch)
4th byte : E
5th byte : Sign (“+”
or “–”)
6th byte : F
7th to 11th bytes : Numerical data
(ex.2.345)
For a non-overflow alarm
1st byte : Channel name (A or B)
2nd byte : Current mode
( N : Current value,
P : Peak-to-peak value,
I : Minimum value,
A : Maximum value)
3rd byte : Unit (M: mm, I: inch)
4th byte : E
5th to 11th bytes : “MErrorM”
Initial setting :
Outputting according to the mode 1 format
(statistical calculations) of the digital printer
P40 (End of sales).
Note
• M means a space.
: (“+” or space)
