Magnescale LT10A-105 - Dimensions

44 (E)
LT10A / LT11A Series
10-4. Dimensions
Cut out Opening
Counter stopper
Unit : mm/inch
68.1/2.68"
74/2.91" 68/2.68" 88/3.46" 78/3.07"
73/2.87"
16/0.63"
33/1.30"
2-R
2
60/2.36"
72/2.83"
72/2.83"
mm
M A X M I N P

P C P H1 2 3 4
P
RESET
SET
P
MODE COMP
mm
M A X M I N P

P C P L1 2 3 4
P
A+B
BA
A
RESET
B
68/2.68"
(71.8)/(2.83")
□68/2.68"
4-R1 or less
15/0.59"
1/0.04"
8/0.31"
68 /2.68"
+1.0 +0.4
+0.039" +0.016"
68 /2.68"
+1.0
+0.4
+0.039"
+0.016"
