42 (E)
LT10A / LT11A Series
∗∗
∗∗
∗ 3: RS-232C (8 pin mini-DIN connector)
Reset, preset value setting/recall, peak-hold start, peak-hold pause,
current value hold, software version read, comparator value setting,
current value/maximum value/minimum value/peak-to-peak measuring
mode selection and output, key lock and release.
∗∗
∗∗
∗ 4: RS-TRG pin
Trigger input for RS-232C data output
∗∗
∗∗
∗ 5: With measuring unit connected.
LT10A-105 105B 105C 205 205B 205C
LT11A-101 101B 101C 201 201B 201C
Maximum, minimum, and peak-to-peak values. Measuring started by the start input of the I/O connector;
update stop by pause input.
—
Can be started with
RS-232C can set
—
Can be started with
RS-232C can set
the BCD terminal.
or start.
the BCD terminal.
or start.
0.001 mm, 0.005 mm, 0.01 mm selectable (0.001 mm (0.0001") is LT11A series only.)
Can be switched
100 m/min 80 m/min
— A+B, A–B, B–A can be set with the direction setting.
Displayed on LCD or the I/O connector’s comparator outputs are all “H” (OFF).
—
BCD alarm
——
BCD alarm
—
terminal “H” (OFF) terminal “H” (OFF)
Resolution, direction, comparator value, preset value, modes, etc.
— BCD sign
Data signalling rate, etc.
— BCD sign
Data signalling rate, etc.
Operating temperature: 0 to 40°C Storage temperature: –10 to 50°C
1.8 W 2.9 W 2.0 W 2.3 W 4.0 W 2.5 W
Approx. 200 g Approx. 230 g Approx. 220 g Approx. 210 g Approx. 270 g Approx. 230 g
Power input connector (3 pins) : DC9.0 to 26.4 V.
DT series
Model
Item
Peak hold function
Resolution
Direction
Maximum response speed
Addition and subtraction function
Alarm
Data storage
Temperature
Power consumption
*5
Mass
Power voltage
Compatible measuring unit
