2 Elements of the measuring
instrument
Height measuring instrument 817 CLT
comprises the following elements:
1
2
3
4
6
5


 
2 Column of the measuring instrument with
measuring slide
3 Control panel with on/off switch
4 Quick measurement function keys
and thumbwheel
5 Ports (back of instrument)
6 Handles on both sides
(with button for air bearing)
2.1 On/off switch
There is an on/off switch for the height
measuring instrument above the control panel.
1

On/off switch
2.2 Control panel
The control panel features a swivel and tilt
joint, which enables individual adjustments.


The user interface of the Digimar software is
displayed on the touchscreen of the control
panel.
