Mahr Digimar 817 CLT User Manual

Mahr GmbH, Digimar 817 CLT
26
5.4 Technical data
ML350 ML600 ML1000
Measuring range 0 - 350mm 0 - 600mm 0 - 1000mm
Measuring range extension 170mm
Resolution 0.01 / 0.005 / 0.001 / 0.0005 / 0.0001mm
Error limit (µm) (1.8+L/600) L in mm
Repeatability: plane (±2σ) 0.5µm
Repeatability: bore (±2σ) 1µm
Perpendicularity deviation 5µm 6µm 10µm
Measuring force 1.0 +/-0.3N
Measuring speeds 5 / 8 / 11 / 15 / 20mm/s
Maximum positioning speed
- manual
- motorized thumbwheel
1000mm/s
80mm/s
Drive motorized
Compressed air supply built-in compressor
Vertical measuring system of the
column
incremental measuring system
Resolution of vertical measuring system 0.1µm
Working temperature 20°C
Operating temperature** 10 °C to 40°C
Storage temperature -10 °C to 60°C
Permitted relative humidity max. 65 % (non-condensing)
Temperature sensor error limit +/-0.25°C
Power supply 12VDC / 3.8A / Type FW7405M/12
Supply voltage / mains frequency 110 - 230 V AC / 50 - 60Hz
Operating time, maximum 14h
Battery voltage 7.2V
Battery capacity 11500mAh
Rechargeable battery type Lithium-ion battery
Protection rating IP40
