5.6 Accessories
5.6.1 Carriers and holders for measuring anvils
Order no. Description Type Holder Application
4429154 Carrier 817h1 ø6mm universal
4429219 Carrier 817h2 ø6mm for large measuring depths
4429220 Carrier 817h4 ø8mm universal
4429454 Carrier with
pivoting holder
817h5 ø6mm combined with the cylinder
keys
3015917 Probe holder Gk/8 M3 / ø4mm for delicate workpieces
4429256 Probe holder incl.
measuring anvil
ø2.0mm
KM2 M2 for delicate workpieces
5.6.2 Measuring anvils
Order no. Description Type Holder Suitable for
4305870 Measuring anvil
ø1.0mm,
carbide,
l=14.5mm
800ts M2 KM2, TMT120, TMT120S
4305850 Measuring anvil
ø2.0mm,
carbide,
l=14.5mm
800ts M2 KM2, TMT120, TMT120S
4305871 Measuring anvil
ø3.0mm,
carbide,
l=14.5mm
800ts M2 KM2, TMT120, TMT120S
4309051 Measuring anvil
ø2.0mm,
ruby, l=14.5mm
800tsr M2 KM2, TMT120, TMT120S
