4 Commissioning
4.1 Initial commissioning
The height measuring instrument must be
used on a granite plate of quality class 0 or 1.
The measuring plate must stand on vibration-
free ground (vibrations from stamping die or
the like must not be transmitted).
The height measuring instrument must be
correctly assembled and connected before
initial commissioning.
The AC adapter must be connected to the
charging socket. After approx. 5 minutes
the battery is charged enough for the height
measuring instrument to be switched on.
4.1.1 Switching ON
•
To switch on the height measuring
instrument, press the on/off switch above
the control panel.
•
As soon as the operating system of the
height measuring instrument starts up, the
user interface of the Digimar software will
appear on the control panel.
4.1.2 Basic settings
When starting up for the first time, some
parameters such as language and unit of
measurement need to be set. To do so:
• Press the
button in the menu bar of the
user interface.
•
In the "Settings" menu that now appears,
press the button for the "Instrument
settings" in the menu.
The "Instrument settings" screen is
displayed in the user interface.
•
In this screen, set the current date, the
time and the language for the Digimar
software.
•
If applicable, specify a time interval for
the height measuring instrument to
automatically switch off.
•
If applicable, specify a time interval for
the display backlight to automatically
switch off.
•
If applicable, set the brightness for the
backlight of the display.
•
Activate password protection if
necessary.
•
Once all of the settings have been
defined, repeatedly press the button
in the menu bar of the user interface to
apply the entries and close the "Settings"
menu.
The settings options are explained in
detail in the online help of the Digimar
software.
