Mahr Maxum III - Changing Digital Resolution

18
Maxuum III Digital Electronic Indicator 2239028 Rev D
Figure 9
3.5 Changing Digital Resolution
1. Enter Setup Mode.
2. Press the RESET button until the letter r shows in the last
digital position of the LCD display. The r indicates the
digital Range setup feature.
3. Press the RESET button once to enter the Digital Resolu-
tion setup feature. Note that there is no half-digit icon
used for this setup feature.
Figure 10
4. Press the HOLD button to toggle between standard
digital resolution and high digital resolution selections.
Resolution selections are dependent on indicator model
and digital range selection (see, ‘Overlay Selection Table’
on page 20).
