37
Maxuum III Digital Electronic Indicator 2239028 Rev D
8. With the Zero block in place, press and release the
Auto-Zero button for final zero setting against the zero
master. The indicator should now be in its operating
mode and ready for measurements.
NOTE: For Indicators or Indicating Units having counterclock-
wise display direction, readings will have opposite signs.
** NOTE: Indicates factory calibrated range (75% of Full Scale).
6.0 Parts and Service
Maxum III Indicator parts and service are available from Mahr
Inc., Providence, RI, U.S.A. Contact your Mahr Federal represen-
tative in Providence. Carefully pack items to prevent damage in
shipment. Include a brief description of the problem and the
name, address and telephone number of a person to contact if
we have any questions
Digital
Range
Range Type
‘Zero’ Gage
Block
Reading with
‘Zero’ Block
should be:
Second
Gage Block
Reading with
Second Block
Should be:*
r0.0199 in
Short
0.115 in 0.00000 0.100 in -0.01500
**
r0.0400 in
Short
0.130 in 0.0000 0.100 in -0.0300
**
r0.100 in
Long
0.175 in 0.0000 0.100 in -0.0750
r0.199 mm
Short
1.15 mm 0.0000 1.00 mm -0.1500
r1.000 mm
Short
1.75 mm 0.000 1.00 mm -0.750
r1.99 mm
Long
2.50 mm 0.000 1.00 mm -1.50
*See Note Above.
