Removing and installing camshaft
103
Installing camshaft
Fig. 3
Oil and insert the valve tappets.
Oil the camshaft bearing bushings.
Fit inserting mandrel (special tool) to the camshaft.
Oil the camshaft and insert carefully.
Caution:
Do not damage the bearings.
Fig. 4
In doing so, note the marking of the crankshaft and
camshaft toothed gear.
Fig. 5
If the camshaft cover in the crankcase has been
removed, insert it as follows:
D Remove grease from bore hole and cover
D Apply the sealing compound ”Hylomar” to the
bore hole and cover, including bevel
D Carefully press in the cover as straight as poss-
ible
D Ensure there are no oil leaks
