Man D 2842 LE 620 - Service Data; Piston and Piston Ring Specifications

Ø
Limit values
Service Data
Dimensions
141
Flywheel and starter gear ring
Ø Flywheel: 432,490−432,645 mm
Internal gear ring Ø:
432,000−432,155 mm
Interference: 0,335−0,645 mm
Installation temperature: 200−230_C
m = 54,2 kg (with gear ring)
J = 1,98 kgm
2
Number of teeth: Z = 160, module 3
Matching gear: Starter pinion (Z = 9)
Backlash: 0,6−0,9 mm
