Removing and installing speed pickup
133
Fig. 1
The speed pickup and the auxiliary speed pickup
are fitted to the flywheel housing, at bottom right.
Only the lower transmitter is installed on engine D
2842 LE 620.
For removal, disconnect cable from plug connec-
tion (arrow).
Fig. 2
Remove mounting bolt and take off transmitter.
The unit is installed in reverse sequence to re-
moval procedure.
