Replacing the bearing race
68
Replacing bearing race
Remove flywheel, see page 65.
Fig. 1
If the shaft sealing ring on flywheel side is re-
placed, it is also recommended to replace the
bearing race of the flywheel.
Pull off the bearing race to be exchanged using a
puller (special tool, see Page163, no. 12.2).
Fig. 2
Insert the new bearing race in the drift (special
tool) in such a way that the inner bevelled side
faces the flywheel when fitted later.
Carefully warm up the drift with bearing race.
The installation temperature of the bearing race is
approx. 150_C.
Fig. 3
Press in the bearing race as far as it will go.
Fig. 4
Seal the gap between flywheel and bearing race
with “Antipor 46”.
