Special tools
163
Fig. no. Designation Item number
1 Engine cranking device
with standard ratchet
80.99626−6008
80.99627−0001
2 Special spanner (WAF 17) for injection pressure lines 80.99603−0025
3 Special spanner (WAF 19) for injection pressure lines 80.99603−0310
4 Wrench socket for cylinder head bolts (Torx) 08.06143−0215
5 Socket spanner for injection line on the cylinder head 80.99603−6019
6 Tester for checking for leaks at nozzle holder seat, pressure pipe and lea-
kage oil duct
80.99620−0029
7 Adapter
with compressed air connection
in conjunction with tester 6
with the following reducing bolted connection:
2x reducing connection D8134A-RED15/10-PLA3C
2x reducing connection D8134A-RED22/15-PLA3C
1x screw plug D813A-VKA 10A3C
80.99620−0033
81.98130−0614
82.98130−0174
82.98130−0194
82.90310−0023
8 Mounting plate for cylinder head and rocker arm bearing housing 80.99606−6089
9 Straightedge for cylinder heads 80.99606−0582
10 Pressing mandrel for cassette seal in conjunction with handle 12.1 80.99617−0191
11 Driving mandrel for seal in timing case
comprising:
11.1 Guide sleeve 80.99604−0068
11.2 Pressing plate in conjunction with handle 12.1 80.99604−0069
12 Driving mandrel for race on flywheel in conjunction with handle 12.1 80.99617−0017
12.1 Attachment handle for all press−in plates 80.99617−0129
12.2 Puller for bearing race on the flywheel 80.99601−6017
13 Puller for front crankshaft bearing race 80.99601−0076
14 Rotation angle measuring device 80.99607−0134
