Ø
Limit values
Service Data
Dimensions
150
Drive wheel with oil pump wheel
14,5−14,7 mm
Shaft: 21,930−21,940 mm
Bore in drive gear: 21,870−21,885 mm
Press on force: 12000 N
Backlash:
Drive wheel and crankshaft wheel:
0,099−0,451 mm
Oil pump delivery rate
The speeds are pump speeds.
Oil pump speed: engine speed x 0,977 (i = 1,023)
Delivery rates with SAE 20 oil at 90_C and 6 bar oil pressure
at n = 585 rpm 67 l/min
at n = 2247 rpm 279 l/min
