Removing and installing the injectors
33
Fig. 4
Remove coolant bleed pipe, rail carrier and leak-oil
pipe.
Fig. 5 and Fig. 6
Unscrew the mounting bolt Á of the connector fit-
ting and pull the pressure pipe fittings  out of the
cylinder head.
Fig. 7
Unscrew the mounting bolt of the pressure flange
(see item À Fig. 6).
2
3
1
