Removing and fitting vibration damper,
replacing front crankshaft gasket
62
Replacing the front crankshaft gasket
Fig. 4
Loosen the mounting bolts of the cover.
Fig. 5
Remove the cover.
Only replace the front crankshaft gasket as a com-
plete unit,
i.e. replace the bearing race and the radial shaft
sealing ring.
Replacing the bearing race
Fig. 6
A stripping device (special tool) is required to re-
move the bearing race.
Fig. 7
Pull off the bearing race.
