Manitou MAN'GO 12 - Basket Control Station - Safety Features; Dead Mans Pedal and Buzzer Operation; Safety Harness Points and Safety Rail

37 - “DEAD MAN'S” PEDAL
- This pedal is fixed on the platform’s floor.
- This pedal must be pressed to perform movements from the basket console.
- When the pedal is released, no control can be used.
38 - BUZZER
- This buzzer is activated when the machine reaches the maximum authorised level
of tilt or is overloaded.
- Sounding intermittently: the machine is tilting. When the authorised tilt limit
threshold is crossed, all movements are blocked except for lowering the arms to
enable return to an acceptable level.
- Sound continuously: the machine is overloaded. When the platform is overloaded,
all movements are blocked. It is essential to unburden the machine so that you
can manoeuvre.
39 - SAFETY HARNESS HOOK-UP POINTS
- These attachments must be used to fasten the harness when operators are in the
basket.
- Only one personn is fasten for one safety harness hook-up points.
40 - SAFETY RAIL
You must hold the rail to climb into the basket so that the rail does not fall back as the
operator climbs in.
t
IMPORTANT
t
Do not hold the safety rail with a collar or string.
41 - GENERATOR ACTIVATION BUTTON (OPTION)
See the “DESCRIPTION AND USE OF THE OPTIONS” Section, page 2-50.
39
39
40
41
2 - 37
647533 (09/10/2015) MAN'GO 12
