C7 – TIGHTNESS OF THE HYDRAULIC ENGINE FIXING BOLTS ON THE CHASSIS
CHECK
- The tightness of these bolts must be checked, at the latest, after 50 hours of operation. This check must then be repeated
after every 250 hours of operation.
- The bolts’ tightening torque is 11,1 daN.m ± 10 %.
- 1 daN = 1 Kg.
C8 – ARM POSITION SENSORS
CHECK
For this operation, fold the arms into transport position.
- Make a translation movement at transport speed
- Raise the arm and the telescope
- Move forward
- The platform should switch to Work speed
t
IMPORTANT
t
If a malfunction occurs, prohibit use of the platform. Contact your dealer.
C9 – TILT SENSOR
CHECK
For this operation, unfold the arms.
- Set the platform in a position where the tilt is greater than the permissible level (see: 2 – DESCRIPTION: SPECIFICATIONS).
- The movements for extending the telescope and raising the arms should be blocked (the tilt light is lit in the basket; the
buzzer is activated intermittently in the basket).
t
IMPORTANT
t
If a malfunction occurs, prohibit use of the platform. Contact your dealer.
C10 – OVERLOAD SENSOR
CHECK
For this operation, unfold the arms.
- Set the platform in a position where the tilt is greater than the permissible level (see: 2 – DESCRIPTION: SPECIFICATIONS).
- All movements should be blocked (the tilt light is lit in the basket; the buzzer is activated intermittently in the basket).
t
IMPORTANT
t
If a malfunction occurs, prohibit use of the platform. Contact your dealer.
C11 – COOLANT CIRCUIT HOSES
CHECK
t
IMPORTANT
t
If the coolant circuit hoses are damaged or the coolant is leaking, this may cause overheating or severe burns.
- Open the rear cover.
- Visually check the condition of the cooling circuit hoses and the tightening collars. If these are blistered, hardened or
cracked, replace them immediately. (Contact your dealer)
3 - 21
647533 (09/10/2015)
MAN'GO 12
